Display Annotation
Item 24 refers to the trace modes of the analyzer. The first letter W
indicates that the analyzer is in clear-write mode. The second letter is
1, representing trace 1. The trace 2 trace mode is S2, indicating trace 2
(2) is in the store-blank mode (S). The trace mode annotation for trace 3
is displayed under the trace mode annotation of trace 1. The trace 3
trace mode is S3, indicating trace 3 (3) is in the store blank mode (S).
Refer to Table 2-4 for other valid trace mode annunciators.
A # in front of display annotation indicates that the function is
uncoupled. (Refer to “Auto Couple” in Chapter 6)
Refer to the following tables for the screen annotation codes for trace,
trigger, and sweep modes.
Table 2-4 Screen Annotation for Trace Mode
Screen
Annotation
Description
W Clear Write
M Maximum Hold
V View
S Store Blank
m Minimum Hold
Table 2-5 Screen Annotation for Trigger Mode
Screen
Annotation
Description
F Free Run
L Line
V Video
E External
Table 2-6 Screen Annotation for Sweep Mode
Screen
Annotation
Description
C Continuous
S Single Sweep
