Agilent Technologies E4445A Service Guide

Chapter 10 233
Replaceable Parts Lists and Locations
Replaceable Parts
Spring-Wire Frame (for
two front bottom feet)
1460-1345 X X X X X X
Front Frame Assy.
(includes EMI gaskets
and “trim strips”)
E4406-60155 X X X X X X
Rear Frame Assy.
(includes EMI gaskets)
E4406-60154 X X X X X X
Front Dress Panel
(includes keyboard
overlay label)
E4440-60080 X X X X X X
Deck Assy. (chassis) E4440-00028 X X X X X X
Strap Handle Assembly E4440-60066 X X X X X X
Front Shield E4440-00050 X X X X X X
Keypad E4440-40003 X X X X X X
RPG Knob 0370-3229 X X X X X X
Nut for RPG, M6x0.5 0535-0163 X X X X X X
Volume Knob 0370-3230 X X X X X X
Plug, Hole 0.5D, Nylon
(for BNC hole)
6960-0149 X X X X X X
Plug, Hole 0.25D, Nylon
(for SMA hole)
6960-0076 X X X X X X
Line Key (push rod)
Compression Spring
Retainer Ring
E4406-40005
1460-2580
0510-1055C
XXXXXX
Dress Panel, SCSI E4406-00017 X X X X X X
Display EMI Filter 1000-1001 X X X X X X
Display Mount
(serial prefix below
US/MY/SG 4611 order
Flat Panel Display
Retrofit Kit. See Table
10-1.)
(If the kit is
previously
installed, the
display and
display mount
will look like
Figure 10-29)
XXXXXX
Display Mount
(serial prefix US/MY/SG
4611 and above)
E4406-40013 X X X X X X
Table 10-2 Mechanical Parts
Description Part Number E4440A E4443A E4445A E4446A E4447A E4448A
