Chapter 10 273
Replaceable Parts Lists and Locations
Hardware
Item Description Agilent Part Number
A36 A36 Millimeter Preamp 50 GHz (Option 110) 0955-1617
AT3 AT3 3 dB Attenuator (Option 110) 08490-60010
SW3 SW3 Coaxial Switch (Option 123) N1810-60052
SW4 SW4 Millimeter XFER Switch 50 GHz (top
switch) (Option 110)
87222-60015
W89 W89, Cable, coax, Switch 3 bottom port to
RHYTHM/SBTX (Option 123)
E4440-60373
W93 W93, Cable, coax, Unpreselected mixer to
Switch 3 coax switch top port (Option 123)
E4440-60298
W94 W94, Cable, coax, SW3 coax switch center
connector to 3rd Converter (Option 123)
E4440-60373
W96 W96, Cable, ribbon, Driver board J9 to coax
switch (Option 123)
E4440-60427
W103 W103, Cable, semi-rigid, Preamp In from
Switch 4 port 2 (Option 110)
E4446-20078
W104 W104, Cable, semi-rigid, Preamp out to Switch
4 port 3 (Option 110)
E4446-20083
1 Bracket, Switch (Option 110, 123) E4440-00063
2 Bracket, Unpreselected Mixer (Option 110,
123)
E4440-00062
3 Bracket, Preamp (Option 110) E4440-00075
4 Bracket, Coax Switch (Option 123) E4440-00076
5 Screw M3 X 0.5 16 MM (Option 123) Attaches
SW3 to to bracket
0515-0375
