Chapter 10 299
Replaceable Parts Lists and Locations
Hardware
Item Description
Agilent Part
Number
1 Screw M3x0.5 8mm-LG
(Crest Washer-Pan Head-TORX)
0515-0372
3 W47 Cable (97), coax, Preselector Tune Out
A13 Front End Driver to Rear Panel
8121-0153
4 Dress Panel, rear E4440-00059
5 W22 Cable (70), coax, Ext Ref In from rear
panel to A11 Reference Assy P1
8120-5053
6 W21 Cable (90), coax, 10 MHz Out from A11
Reference Assy P2 to rear panel
8120-5053
7 W19 Cable (40), coax 321.4 MHz IF OUT
from A10 3rd Converter J4 to rear panel
8121-0149
8 W14 Cable (30), coax, TRIGGER 2 OUT to
A9 2nd LO, J11
8121-0153
9 W13 Cable (20), coax, TRIGGER 1 OUT to
A9 2nd LO, J12
8121-0153
10 W12 Cable (6), coax, TRIGGER IN from
rear panel to A8 Analog IF, P4
8120-5053
11 Screwlock, SCSI 1252-5828
12 Dress Panel, SCSI, shown in Figure 10-32 E4406-00017
12 Cover plate, rear panel, USB/Flash Board
(Option 111, 115)
E4440-00061
13 Rear Frame Assy. (includes EMI gaskets) E4406-60154
14 Deck Assy. (chassis) E4440-00028
15 W75 Cable (41), coax, 70 MHz IF OUT, from
A33 Option card J2 to rear panel (Option
H70)
8121-0705
16 W23 Cable, coax, 28V to rear panel from
A13 Front End Driver
8121-0958
