Overview
Service Equipment You Will Need
3.5 mm (f) to 3.5 mm (f)
(2 Required)
Frequency: DC to 26.5 GHz
VSWR: ≤ 1.05:1
83059B 1250-1749 P
3.5 mm (m) to 3.5 mm (m)
(2 Required)
Frequency: DC to 26.5 GHz
VSWR: ≤ 1.12:1
1250-1748 P
3.5 mm (f) to 3.5 mm (f) Frequency: DC to 34 GHz
VSWR: 1.15:1
1250-1749 P
2.4 mm (f) to 3.5 mm (m)
(for E4446A, 47A, 48A)
Frequency: DC to 26.5 GHz
VSWR: ≤ 1.05:1
11901D A, P
3.5 mm (f) to Type-N (f) Frequency: DC to 18 GHz
VSWR: 1.08:1
1250-1745 A, P
3.5 mm (f) to 2.4 mm (f)
(for E4446A, 47A, 48A)
Frequency: DC to 26.5 GHz
VSWR: 1.05:1
11901B P
BNC (m) to SMA(f) Frequency: DC to 1.3 GHz
VSWR: ≤ 1.13:1
1250-1700 P
Type-N (m) to 3.5 mm (f)
(2 Required,
Opt. BAB 3 Required)
Frequency: DC to 18 GHz
VSWR: ≤ 1.08:1
1250-1744 P
Type-N (f) to 2.4 mm (f) Frequency: DC to 18 GHz
VSWR: ≤ 1.08:1
11903B A, P
Type-N (m)
to 2.4 mm (f)
(for E4446A, 47A, 48A)
Frequency: DC to 18 GHz
VSWR: 1.08:1
11903D P
Type-N (f) to 3.5 mm (m) Frequency: DC to 18 GHz
VSWR: ≤ 1.14:1
1250-1750 A, P
BNC Tee (BNC f,m,f) 1250-0781 A, P
SMB (f) to BNC (f) Frequency: DC to 1.3 GHz 1250-1236 A, P
BNC (f) to SMA (m) Frequency: DC to 1.3 GHz 1250-1200 A, P
BNC (f) to Dual Banana 1251-2277 A, P
3.5 mm (f) to Type-N (m)
Shipped with the 8485 for adapting to the Power
Reference. Only to be used for power sensor
calibration.
08485-60005 A, P
2.4 mm (f) to Type-N (m) Shipped with the 8487 for adapting to the Power
Reference. Only to be used for power sensor
calibration.
08487-60001 A, P
Optional Equipment
10 MHz Distribution
Amplifier
(only needed when using
the 10 MHz Distribution
Amplifier setup)
Symmetricom
5087B
Agilent 5087A A, P
a. A = Adjustments, P = Performance Testing, T = Troubleshooting)
Table 1-3 Required Test Equipment for PSA Series (Continued)
Instrument Critical Specifications Recommended
Agilent Model
Number
Alternative
Agilent Model
Number
Use
a
To Next Page
