Service Equipment You Will Need
BNC
(3 required)
Frequency: DC to 10 MHz
50 Ω Coax BNC (m), both ends
120 cm (48 in.)
10503A A, P, T
Filters
50 MHz Low Pass Cutoff Frequency: 50 MHz
Rejection at 65 MHz: > 40 dB
Rejection at 75 MHz: > 60 dB
Insertion Loss: ~1 dB
VSWR: ≤ 1.5:1
BNC (m) to BNC (f)
0955-0306 Telonic Berkeley
TLA 50-5AB2
P, T
300 MHz Low Pass
(2 Required)
Cutoff Frequency: 300 MHz
Rejection at > 435 MHz: > 45 dB
VSWR: ≤ 1.5:1
BNC (m, f)
0955-0455 Telonic Berkeley
TLP 300-4AB4
P
1.8 GHz Low Pass
(2 Required)
Cutoff frequency: 1.8 GHz
Rejection at > 3 GHz: > 45 dB
Insertion Loss: ~0.25 dB
VSWR: ≤ 1.35:1
SMA (f)
0955-0491 RLC Electronics
L-1636
P
4.4 GHz Low Pass
(2 Required)
Cutoff frequency: 4.4 GHz
Rejection at > 5.5 GHz: > 42 dB
9135-0005 K + L Microwave
ML253-4499/
XU-N/NP
P
1 GHz Low Pass Center frequency: 1 GHz
Rejection at 2 GHz: > 60 dB
0955-0487 RLC Electronics
L-1621
P
1.0001 GHz Notch Center frequency: 1 GHz
BW: 6 MHz
Rejection at 13 MHz from CF: > 50 dB
Trilithic
CFN-2-1000.1
P
1 GHz Band Pass Center frequency: 1 GHz
BW: 6 MHz
Rejection at 13 MHz from CF: > 50 dB
0955-1612 K & L Microwave
4C45-1000/X6-0/0
P
Adapters
Type-N (f) to Type-N (f) Frequency: DC to 18 GHz
VSWR: 1.13:1
1250-1472 P
Type-N (m) to Type-N (m) Frequency: DC to 18 GHz
VSWR: ≤ 1.13:1
1250-1475 P
Type-N (f) to BNC (m) Frequency: DC to 1.3 GHz
VSWR: 1.13:1
1250-1477 P, T
Type-N (m) to BNC (m) Frequency: DC to 1.3 GHz
VSWR: 1.13:1
1250-1473 P, T
Type-N (m) to
3.5 mm (m)
Frequency: DC to 18 GHz
VSWR: ≤ 1.08:1
1250-1743 P
Type-N (m) to BNC (f) Frequency: DC to 1.3 GHz
VSWR: ≤ 1.13:1
1250-1476 P
Table 1-3 Required Test Equipment for PSA Series (Continued)
Instrument Critical Specifications Recommended
Agilent Model
Number
Alternative
Agilent Model
Number
Use
a
