Chapter 1 29
Overview
Service Equipment You Will Need
Millimeter Power Splitter
(for E4446A, 47A, 48A)
Frequency: 10 MHz to 50 GHz
VSWR: ≤ 10 MHz to 18 GHz: < 1.29:1
18 GHz to 26.5 GHz: < 1.20:1
26.5 to 40 GHz: < 1.50:1
40 GHz to 50 GHz: < 1.65:1
Tracking Error: < ± 0.40 dB
Connector: 2.4 mm (f)
11667C P
Directional Bridge Frequency Range: 5 MHz to 3 GHz
Directivity: ≤ 5 MHz: 30 dB
5 MHz to 2 GHz:40 dB
2 GHz to 3 GHz: 30 dB
VSWR: ≤ 2 GHz: ≤ 1.15:1
≤ 3 GHz: ≤ 1.22:1
Insertion Loss: ≤ 1.5, +0.1 dB/GHz
Coupling (nominal): 16 dB
Connector: Type N (f)
86205A P
Directional Coupler 2 GHz to 20 GHz
Directivity > 16 dB
Transmission arm loss: < 1.5 dB (nominal)
Coupled Arm Loss: ~10 dB (nominal)
VSWR: ≤ 1.35:1
Connector: SMA (f)
87300B P
DC Probe 11002A 11003A A
High Frequency Probe Frequency Range: 300 kHz to 3 GHz
Input Resistance: 1 M Ω (nominal)
85024A T
Negative Detector 50 MHz to 26.5 GHz
± 0.6 dB to 18 GHz
33330C A
Bias Adjustment Board E4440-60041 A
Cables
3.5 mm (m) to 3.5 mm (m)
(2 required)
Frequency: DC to 26.5 GHz
Length: ≤ 92 cm (36 in)
Insertion Loss: ~2 dB
VSWR: DC to 18 GHz: ≤ 1.25:1
18 GHz to 26.5 GHz: ≤ 1.35:1
8120-4921 A, P
2.4 mm (f) to 2.4 mm (m)
(for E4446A, 47A, 48A)
Frequency: DC to 50 GHz
Length: ≤ 24.9 cm (9.8 in)
Insertion Loss: ≤ 26 GHz, ~4 dB
Insertion Loss: ≤ 40 GHz, ~5 dB
Insertion Loss: ≤ 50 GHz, ~6 dB
VSWR: ≤ 26.5 GHz: ≤ 1.30:1
≤ 40 GHz: ≤ 1.40:1
≤ 50 GHz: ≤ 1.55:1
8120-6164 A, P
Type-N
(2 required)
Frequency: 10 MHz to 8 GHz
Precision Type-N (m), both ends
62 cm (24 in.)
VSWR: ≤ 18 GHz: 1.4:1
Insertion Loss: 1.5 dB
11500C A, P, T
Table 1-3 Required Test Equipment for PSA Series (Continued)
Instrument Critical Specifications Recommended
Agilent Model
Number
Alternative
Agilent Model
Number
Use
a
