Agilent Technologies E4445A Service Guide

28 Chapter 1
Overview
Service Equipment You Will Need
Attenuator Driver Compatible with the 8496G and 8494G step
attenuators.
11713B 11713A P
3dB
Fixed Attenuator
3 dB Type-N (m, f)
Frequency: 50 MHz
VSWR: at 50 MHz: ≤ 1.05:1
8491A
(Option 003)
8491B/C
(Option 003)
P
6dB
Fixed Attenuator
6 dB Type-N (m, f)
VSWR: at 50 MHz: ≤ 1.05:1
8491A
(Option 006)
8491B/C
(Option 006)
P
10 dB
Fixed Attenuator
10 dB Type N (m, f)
Frequency: 50 MHz
VSWR: at 50 MHz: ≤ 1.05:1
8491A
(Option 010)
8491B/C
(Option 010)
P
10 dB
Fixed Attenuator
10 dB 3.5 mm (m, f)
VSWR: 321.4 MHz to 19.5 GHz: ≤ 1.1:1
8493C
(Option 010)
A, P
20 dB
Fixed Attenuator
20 dB Type-N (m, f)
Accuracy: ± 0.5 dB
VSWR: 100 kHz to 3 GHz: ≤ 1.20:1
8491A
(Option 020)
8491B/C
(Option 020)
A
20 dB
Fixed Attenuator
20 dB 3.5 mm (m, f)
Accuracy: ± 0.5 dB
VSWR: DC to 7.1 GHz: ≤ 1.20:1
8493C
(Option 020)
A, P
30 dB
Fixed Attenuator
30 dB
Accuracy: ± 0.05 dB
VSWR: 1.05 @ 50 MHz
(for use with Low Power Sensors)
11708A A, P
Terminat ions
Type-N (m) 50 Ω
Frequency: 10 kHz to 18 GHz
VSWR: 4 GHz: ≤ 1.05:1
909A
(Option 012)
P, T
3.5 mm (f) 50 Ω
VSWR: ≤ 26.5 GHz: ≤ 1.12:1
909D P
2.4 mm (f)
(for E4446A, 47A, 48A)
50 Ω
Frequency: 10 kHz to 50 GHz
85138B P
BNC (m) 50 Ω
Frequency: 10 kHz to 50 GHz
1250-0207 P
Miscellaneous Devices
RF Power Splitter Frequency: 9 kHz to 3 GHz
VSWR: ≤ 1.10:1
Connector: Type-N (f)
11667A P
Microwave Power Splitter
(for E4440A, 43A, 45A)
Frequency: 10 MHz to 26.5 GHz
VSWR: 10 MHz to 3 GHz: < 1.06:1
3 GHz to 26.5 GHz: < 1.22:1
Tracking Error: < ± 0.25 dB
Connector: 3.5 mm (f)
11667B
(Option H30)
11667B
(std.)
P
Table 1-3 Required Test Equipment for PSA Series (Continued)
Instrument Critical Specifications Recommended
Agilent Model
Number
Alternative
Agilent Model
Number
Use
a
