Chapter 1 27
Overview
Service Equipment You Will Need
High Sensitivity Microwave
Power Sensor
(for Option 110 on
E4440A, 43A, 45A)
Frequency Range: 50 MHz to 26.5 GHz
Amplitude Range: -70 to -20 dB
Zero Set: ± 20 pW
Zero Drift: < ± 4 pW
Measurement Noise: < 4 pW
Cal Factor Uncertainty (std): < 2.6%
VSWR: 50 MHz to 100 MHz: 1.19:1
100 MHz to 4 GHz: 1.15:1
4 GHz to 12 GHz: 1.19:1
12 GHz to 18 GHz: 1.25:1
18 GHz to 26.5 GHz: 1.29:1
Input Connector: 3.5 mm (m)
8485D 8487D A, P
High Sensitivity Microwave
Power Sensor
(for Option 110 on
E4446A, 47A, 48A)
Frequency Range: 50 MHz to 50 GHz
Amplitude Range: -70 to -20 dB
Zero Set: ± 20 pW
Zero Drift: < ± 4 pW
Measurement Noise: < 4 pW
Cal Factor Uncertainty (std): < 4.5%
VSWR: 50 MHz to 100 MHz: 1.19:1
100 MHz to 4 GHz: 1.15:1
4 GHz to 12.4 GHz: 1.20:1
12.4 GHz to 18 GHz: 1.29:1
18 GHz to 34 GHz: 1.37:1
34 GHz to 40 GHz: 1.61:1
40 GHz to 50 GHz: 1.89:1
Input Connector: 2.4 mm (m)
8487D A, P
Standards
Frequency Standard Frequency: 10 MHz
Accuracy: < ±1 e10
-10
Symmetricom
5071A
Agilent 5061B,
5071A
A, P
50 MHz,
-25 dBm Calibrator
Frequency Drift: < 2.5 kHz
Typical VSWR: 1.06:1
Output Power Variation: ±.004 dB
Total Harmonic Content: -45 dBc
Z5602A
Opt H51
for Type N
Opt H35 for BAB
Opt H24 for
E4446A, E4448A
A
Attenuators
10 dB
Step Attenuator
Range: 0 to 110 dB
Accuracy:
Characterized by standards lab to:
±0.005 + 0.005/10 dB step
f
Calibrated at 50 MHz
VSWR: at 50 MHz: ≤ 1.05:1
8496G 8496H P
1dB
Step Attenuator
Range: 0 to 11 dB
Accuracy:
Characterized by standards lab to: ±0.005 dB
f
Calibrated at 50 MHz
VSWR: at 50 MHz: ≤ 1.05:1
8494G 8494H P
Attenuator
Interconnect Kit
Type N connector kit to connect 8496G to 8494G 11716A P
Table 1-3 Required Test Equipment for PSA Series (Continued)
Instrument Critical Specifications Recommended
Agilent Model
Number
Alternative
Agilent Model
Number
Use
a
