26 Chapter 1
Overview
Service Equipment You Will Need
RF Power Sensor
(2 required)
Frequency Range: 100 kHz to 3 GHz
Amplitude Range: −30 to +20 dBm
Zero Set: ± 50nW
Zero Drift: < ± 10 nW
Measurement Noise: < 110 nW
Cal Factor Uncertainty (std): < 1.6%
VSWR 50 MHz: ≤ 1.05
100 kHz to 1 MHz: ≤ 1.20:1
1 MHz to 2 GHz: ≤ 1.10:1
2 GHz to 3 GHz: ≤ 1.30:1
Option H84 Cal Factor: Characterized by
standards lab to: ± 0.6%
e
Input Connector: Type-N (m)
8482A
(Option H84)
8482A STD
(Will increase
measurement
uncertainty)
A, P
Power Sensor
(for Option B7J)
Frequency Range: 10 MHz to 3 GHz
Amplitude Range: −30 to +20 dBm
Zero Set: ± 50nW
Zero Drift: < ± 10 nW
Measurement Noise: < 110 nW
Cal Factor Uncertainty (std): < 1.6%
VSWR: 50 MHz: ≤ 1.10:1
50 MHz to 3 GHz: ≤ 1.18:1
Option H84 Cal Factor: Characterized by
standards lab to: ± 0.6%
e
Input Connector: Type-N (m)
8481A
(Option H84)
8481A, STD
(Will increase
measurement
uncertainty)
P
Microwave Power Sensor
(for E4440A, E4443A,
E4445A)
Frequency Range: 50 MHz to 26.5 GHz
Amplitude Range: -30 to +20 dB
Zero Set: ± 50nW
Zero Drift: < ± 10 nW
Measurement Noise: < 110 nW
Cal Factor Uncertainty (std): < 2.3%
VSWR: 50 MHz to 100 MHz: 1.15:1
100 MHz to 2 GHz: 1.10:1
2 GHz to 12.4 GHz: 1.15:1
12.4 GHz to 18 GHz: 1.20:1
18 GHz to 26.5 GHz: 1.25:1
Input Connector: 3.5 mm (m)
8485A 8487A A, P
Millimeter Power Sensor
(for E4446A, E4447A,
E4448A)
Frequency Range: 50 MHz to 50 GHz
Amplitude Range: -30 to +20 dBm
Zero Set: ± 50nW
Zero Drift: < ± 10 nW
Measurement Noise: < 110 nW
Cal Factor Uncertainty (std): < 4.5%
VSWR: 50 MHz to 100 MHz: 1.15:1
100 MHz to 2 GHz: 1.10:1
2 GHz to 12.4 GHz: 1.15:1
12.4 GHz to 18 GHz: 1.20:1
18 GHz to 26.5 GHz: 1.25:1
26.5 GHz to 40 GHz: 1.30:1
40 GHz to 50 GHz: 1.50:1
Input Connector: 2.4 mm coaxial (m)
8487A A, P
Table 1-3 Required Test Equipment for PSA Series (Continued)
Instrument Critical Specifications Recommended
Agilent Model
Number
Alternative
Agilent Model
Number
Use
a
