Agilent Technologies E4445A Service Guide

368 Chapter 11
Assembly Replacement Procedures
Vertical Board Assemblies (Standard Instrument)
Figure 11-40 Vertical Board Assembly Cables
Item Description Item Description
1 A5 Power Supply 6 A10 3rd Converter Assembly
2 A6 SCSI Interface Board or A39
USB/Memory Board
7 A11 Reference Assembly
3 A7 Digital IF Assembly 8 A12 LO Synthesizer Assembly
4 A8 Analog IF Assembly 9 A13 Front End Driver Board
5 A9 2nd LO/ Fan Control Assembly
W44
W18
W17
W12
W1
W10
W15
W14
W13
W11
W10
W24
W19
W20
W11
W16
W22
W21
W16
se832a
