Agilent Technologies E8364C Service Guide

6-12 Service Guide E8364-90038
Replaceable Parts PNA Series Microwave Network Analyzers
Replaceable Parts Listings E8362C, E8363C, E8364C
Front Panel Assembly, Back Side, All Options
Reference
Designator
Part Number Qty Description
A1 N5230-40002 1 Keypad assembly
A2 N5230-60045
1
Display assembly (Includes the following parts; not separately orderable.)
➊–LCD display, 8.4-inch, 1024 x 768 pixels
➋–Machine screw, M2.5 x 8 pan head
➌–Display ribbon cable
➍–Cable clamp (for display ribbon cable)
➎–Cable clamp (for inverter cable)
➏–Display bracket
➐–Cable clamp (for display cables and touchscreen cable)
A3 N5230-60132 1 Front panel interface board
➀
N5230-20225
Was N5230-20125
1Front frame
➁
8160-0660 1 RFI gasket
➂
N5230-40003 1 Touch screen rubber boot
➃
E6601-61028 1 Inverter cable
➄
2090-0959 1 Touch screen display, 8.4-inch, 4096 x 4096 pixels
➅
0515-0430 13 Machine screw, M3.0 x 6 pan head
➆
0950-4482 1 Inverter board
➇
0515-0372 8 Machine screw, M3.0 x 8 pan head
➈
N5230-00017
Was N5230-00013
1 Inverter board shield
➉
0515-1974 2 Machine screw, M2.5 x 4 pan head
0960-2796 1 Touch screen controller board
N5230-61002 1 Touch screen controller cable
N5230-60131
1 USB connector board
8160-1731
1 EMI gasket, D-shape, urethane, 4 mm W x 154 mm L
0400-0996
2 Grommet, oval, neoprene
11
12
13
14
15
