6-76 Service Guide E8364-90038
Replaceable Parts PNA Series Microwave Network Analyzers
Replaceable Parts Listings E8362C, E8363C, E8364C
External Hardware and Parts, All Options
Ref. Desig. Part Number Qty Description
A1 Keypad assembly
Refer to “Front Panel Assembly, Back Side, All Options” on page 6-12.A2 Display assembly
RPG Front knob
➀
E8356-00011 1 Inner cover
➁
N5230-00011 1 Outer cover
➂
5041-9611 4 Rear feet
➃
0515-1619 4 Machine screw, M4.0 x 25, pan head
➄
E4400-60026 2
Strap handle assembly (includes item
➅
)
➅
0515-0710 4 Machine screw, M5.0 x 18, flathead
➆
5041-9167 4 Bottom feet
5021-2840 4 Key lock (for securing bottom foot)
➇
5041-9183 2 With handles—front handle side trim
5041-9174 2 Without handles—trim strip, filler
➈
5063-9205 2 Front handle
➉ E8361-20067 2 Clip, retainer
0515-1644 2
Machine screw M3.0 x 12, flat head (for retainer clip, item
➉
)
