7-38 Service Guide E8364-90038
Repair and Replacement Procedures PNA Series Microwave Network Analyzers
Removing and Replacing the A19 Splitter E8362C, E8363C, E8364C
Removing and Replacing the A19 Splitter
Tools Required
• T-10 TORX driver (set to 9 in-lb)
• T-20 TORX driver (set to 21 in-lb)
• 5/16-inch open-end torque wrench (set to 10 in-lb)
• ESD grounding wrist strap
Removal Procedure
Refer to Figure 7-14 for this procedure.
1. Disconnect the power cord.
2. Remove the outer cover. Refer to “Removing the Covers” on page 7-6. Position the analyzer bottom side
up and raise the receiver deck as shown. Refer to “Raising and Removing the Receiver Deck” on page
7-8 if necessary.
3. With a 5/16-inch torque wrench, disconnect the three semirigid cables (item
①) from the A19 splitter.
4. With a T-10 TORX driver, remove the two mounting screws (item
➁).
CAUTION Be careful not to damage the center pins of the semirigid cables. Some flexing of the cables
is necessary to remove the assembly. Do not over-bend the semirigid cables.
5. Remove the A19 splitter from the analyzer. Observe the
CAUTION above.
Replacement Procedure
1. Reverse the order of the removal procedure.
2. Perform the post-repair adjustments, verifications, and performance tests that pertain to this removal
procedure. Refer to Table 7-2 on page 7-82.
