Agilent Technologies E8364C Service Guide

6-72 Service Guide E8364-90038
Replaceable Parts PNA Series Microwave Network Analyzers
Replaceable Parts Listings E8362C, E8363C, E8364C
Bottom Hardware, All Options
Ref. Desig. Part Number Qty Description
➀
E8364-00002 2 Detector/attenuator/bias tee bracket
➁
0515-0430 10
Machine screw M3.0 x 6 pan head
(Detector brackets-3 ea; front-panel LED board-3; A19 splitter bracket-2; A45
switch bracket-2)
➂
0515-0374 16
Machine screw M3.0 x 10 pan head
(A17-4; A18-4; A20-2: A22-2; mixer bracket-4)
➃
0515-0664 10
Machine screw M3.0 x 12 pan head
(A19-2; A16-4; A45-2; A46-2)
➄
0515-0658 8
Machine screw M2.0 x 6 pan head
(A36-2; A37-2; A47-2; A48-2)
➅
0515-1349 16
Machine screw M3.0 x 30 pan head
(A31–A34-3 ea; A21-4)
➆
E8364-00007 1 Hard disk drive shield, stationary bracket
➇
0515-0666 37
Machine screw M3.0 x 18 pan head
(A35 casting-13; A20-4; A27–A30-3 ea;
A23/A24-4 ea: E8363C/E8364C only)
➈
0515-0372 10
Machine screw M3.0 x 8 pan head
(A35-2; mixer bias board-4; A43-2; A44-2)
➉
0515-1644 8
Machine screw M3.0 x 12 flat head
(A49-8)
1400-3014 1 Cable clamp
0515-2141 4
Machine screw M2.5 x 14 pan head
(A38-2; A39-2)
08720-60182 1 Front-panel LED board
E8364-20115 1 mixer bracket
E8364-60140 1 mixer bias board
5022-1087 2 Test port coupler nut
11
12
13
14
15
16
