6-26 Service Guide E8364-90038
Replaceable Parts PNA Series Microwave Network Analyzers
Replaceable Parts Listings E8362C, E8363C, E8364C
Bottom Assemblies, Option UNL
Ref. Desig. Models Part Number
a
a. Part numbers in italic typeface are for rebuilt exchange assemblies. Refer to “Rebuilt-Exchange Assemblies” on page 6-5.
Qty Description
A16 All E8364-60138 1 Test set motherboard
A17 All
5087-7127
5087-6127
1 LOMA 10
A18 All
5087-7128
5087-6128
1 MA 20
A19 All 5087-7139 1 Splitter
A20 All
5087-7129
5087-6129
1 LODA
A21 E8363C, E8364C
5087-7130
5087-6130
1 SOMA 50
A22 All
5087-7132
5087-6132
1 Switch splitter
A23
A24
E8363C, E8364C 5087-7133 2
Channel R1 detector
Channel R2 detector
A25
A26
E8362C 5086-7968 2
Tes t po rt 1 co u ple r
Tes t po rt 2 co u ple r
E8363C, E8364C 5086-7518 2
Tes t po rt 1 co u ple r
Tes t po rt 2 co u ple r
A27
A30
All
5087-7122
5087-6122
2
Channel A first converter (mixer)
Channel B first converter (mixer)
A28
A29
5087-7145
5087-6145
2
Channel R1 first converter (mixer)
Channel R2 first converter (mixer)
A31
A32
A33
A34
All E8364-60134 4
Channel A receiver module
Channel R1 receiver module
Channel R2 receiver module
Channel B receiver module
A35 All E8364-60135 1 Receiver motherboard
A36
A37
All 33325-60004 2
Step attenuator, 60-dB, port 1 (source)
Step attenuator, 60-dB, port 2 (source)
A38
A39
E8362C 5087-7239 2
Bias tee with cable, port 1
Bias tee with cable, port 2
E8363C, E8364C 5087-7233 2
Bias tee with cable, port 1
Bias tee with cable, port 2
A41 All Hard disk drive assembly. Refer to “Hard Disk Drive Assembly, All Options” on page 6-80.
A49 All E8361-60043 1 IF multiplexer board
➀
E8362C 08493-60017 2 30-dB fixed attenuator (pad)
To Next Page
