7-2 Service Guide E8364-90038
Repair and Replacement Procedures PNA Series Microwave Network Analyzers
Information in This Chapter E8362C, E8363C, E8364C
Information in This Chapter
This chapter contains procedures for removing and replacing the major assemblies of your Agilent
Technologies PNA series microwave network analyzer.
Chapter Seven at-a-Glance
Section Title Summary of Content Start Page
Before Starting the Removal and
Replacement Procedures
Warnings and cautions pertaining to personal safety
and ESD protection.
The proper assembly replacement sequence for your
analyzer.
Page 7-3
Ta bl e of Removal and Replacement
Procedures
A table of removal and replacement procedures and the
corresponding page number where they are located.
Page 7-4
Removal and Replacement Procedures The actual procedures for removing and replacing the
major assemblies in your analyzer.
The procedures occur in assembly reference designator
numerical order.
See Table 7-1
on page 7-4
for specific
procedures.
Post-Repair Procedures A table for the proper tests, verifications, and
adjustments to perform on your analyzer after repair.
Page 7-82
