6-82 Service Guide E8364-90038
Replaceable Parts PNA Series Microwave Network Analyzers
Replaceable Parts Listings E8362C, E8363C, E8364C
Serial ATA Interface
Every PNA shipped prior to January 2009 contains the parallel ATA interface for the hard disk drive (HDD).
Starting January 2009, every PNA shipped contains the serial ATA interface for the hard disk drive (HDD).
The table below lists the contents of the HDD with the serial ATA interface.
Ref. Desig. Part Number Qty Description
N8982A Kit (for
1.1 GHz CPU
board)
Hard disk drive assembly kit with programmed hard disk drive (HDD)
(Includes A41 and items
➀ through ➈, pre-assembled.)
A41 N5230-60050 1 Programmed hard disk drive
➀
E8364-20118 1 Hard disk drive bracket
➁
0515-0664 4 Machine screw, M3.0 x 12 pan head
➂
0515-0372 2 Machine screw, M3.0 x 8 pan head
➃
E8361-20069 2 Bushing
➄
E8361-63125 1 Hard disk drive board
➅
1440-0421 1 U-handle, finger grip
➆
0515-1227 2 Machine screw, M3.0 x 6 flathead (for U-handle)
➇
E8361-20068 1
Nylon spacer
➈
0340-1525 4
Bushing
To Next Page
