6-86 Service Guide E8364-90038
Replaceable Parts PNA Series Microwave Network Analyzers
Replaceable Parts Listings E8362C, E8363C, E8364C
Pulse measurement capability (Option H08) E8363/4CU-H08
IF access (Option H11) E8363/4CU-H11
60-dB source attenuators and bias tees (Option UNL) E8363/4CU-UNL
Fuses
Rear Panel Bias Input Fuse Port 1, Port 2 (0.5 A, 125 V) (Option UNL) 2110-0046
Touch-up Paint
Dove gray (for use on frame around front panel and painted portion of handles) 6010-1146
French gray (for use on cover) 6010-1147
Parchment white (for use on rack mount flanges, rack support flanges, and front panels) 6010-1148
USB Accessories
Mouse 1150-7799
Keyboard (U.S. style) 1150-7896
Read/write CD-ROM N4688A
Rack Mount Kits and Handle Kits
Rack mount kit for use with standard supplied front handles (Option 1CP) 5063-9237
Rack mount flange for use with front handles (two included in 5063-9237) 5022-2809
Rack mount kit for use without front handles (Option 1CM)
1CM042A
Was 5063-9217
Rack mount flange for use without front handles (two included in 1CM042A) 5022-2802
Front handle kit (two handles and hardware) 5063-9230
Front handle (two included in 5063-9230) 5063-9205
Rack mount rail set E3663AC
EMI/RFI Shielding Accessories
7 mm ferrite bead for serial cable 9170-1793
9 mm ferrite bead (spare for parallel port) 9170-1702
ESD Supplies
Adjustable antistatic wrist strap 9300-1367
Antistatic wrist strap grounding cord (5 foot length) 9300-0980
Static control table mat and earth ground wire 9300-0797
ESD heel strap 9300-1126
a. E8363/4C is used to represent a range of model numbers and should be replaced with one of the following,
as appropriate: E8363C or E8364C
Table 6-3 Part Numbers for Miscellaneous Parts and Accessories (Continued)
Description
Model or Part
Number
a
