2-10 Service Guide E8364-90038
General Product Information PNA Series Microwave Network Analyzers
Required Service Test Equipment E8362C, E8363C, E8364C
Equipment
a
Critical Specifications
Recommended
Model or Part
Number
Alternate
Model Number
Use
b
Tools
Extender board N/A E8356-60021 None T
T-8 TORX driver 0.6 N-m (5 in-lb) setting N/A N/A R
T-10 TORX driver
0.5, 0.8, and 1.0 N-m
(4, 7, and 9 in-lb) settings
N/A N/A T,R
T-20 TORX driver 2.4 N-m (21 in-lb) setting N/A N/A T,R
1/4-inch and 5/16-inch
open-end wrench
Thin profile 8710-0510 N/A A,R
5/16-inch, open-end torque
wrench
1.1 and 2.4 N-m
(10 and 21 in-lb) settings (for
semi-rigid cables)
N/A N/A T,R
1-inch, open-end torque
wrench
8.1 N-m (72 in-lb) setting (for
Port 1 and Port 2 connector
nuts)
N/A N/A R
20-mm, open-end torque
wrench
0.9 N-m (8 in-lb) setting (for Port
1 and Port 2 measurement
connections)
N/A N/A R
Static Safety Parts
Adjustable antistatic wrist
strap
N/A 9300-1367 None P,A,T
Antistatic wrist strap
grounding cord (5 foot)
N/A 9300-0980 None P,A,T
Static control table mat and
earth ground wire
N/A 9300-0797 None P,A,T
Miscellaneous
USB flash ROM drive N/A Any None P,A,R
a. Unless specified otherwise, equipment listed is required for all analyzer models.
b. P = Performance tests, A = Adjustments, T = Troubleshooting, R = Repair, V = System verification
