5. Insert the new lamp housing and lamp. A keyway on the lamp housing
allows the housing to be placed in its holder in only one orientation.
Push the housing in as far as it will go.
6. Tighten the thumbscrew.
7. Connect the wire connector.
8. Replace the cover panel and the two cover screws.
9. After the lamp has been changed, reset the MxPro QPCR software
lamp timer to 0. To do this, open the
Lamp Reset and Utilities dialog
box (from the software
Instrument menu) and click the Reset button.
The timer will be set to 0 and the current date will be entered in the
Last date reset field.
Replacing the Fuse
The Mx3000P and Mx3005P instruments use a single slow-acting fuse. The
fuse housing is located adjacent to the power cord inlet in the power entry
module. See Installing the Fuse in Setting Up the System for pictures of the
fuse housing unit.
To replace the fuse, disconnect the instrument from the power source, open
the fuse housing cover and remove the fuse holder from the power entry
module. Replace the fuse with the appropriate fuse type from the table
below and then replace the fuse holder.
Warning High voltage present. Turn off the power switch and remove
the power cord from the power entry module prior to
replacing the fuse.
Instrument Type (Voltage) Replacement Fuse
110–120 V T 10 A, 250 V
200–240 V T 5 A, 250 V
Cleaning the Instrument
Clean the exterior housing of the Mx3000P and Mx3005P systems using
only mild soap and warm water on a soft cloth. Do not use alcohol or
solvent-based cleaners. The wells of the thermal block should be cleaned
with cotton swabs and isopropyl alcohol. Ensure that the block is at room
temperature before cleaning.
Avertissement
Présence de haut voltage. Éteigner l’instrument et
débrancher le cordon d’alimentation de la prise du bloc
d’alimentation avant de remplacer le fusible.
28 Mx3000P and Mx3005P QPCR Systems Setup and User’s Guide
