Making Your First Measurements
Connecting USB, GPIB or LAN
Chapter 2 19
Connecting by USB
The USB interface requires no front panel configuration. USB operation and
configuration is supported by the version of VISA and SICL I/O libraries on your
computer.
1. Switch on and connect the Wireless Connectivity Test Set to your computer
using the supplied Type A to B Mini 5 pin USB cable.
2. The Found New Hardware Wizard appears.
In the prompt select No, not this time, Click Next.
Click Next to install the software automatically.
By installing the Agilent I/O Libraries software, you also installed low-level
drivers. This means you do not need to insert the drivers CD when the wizard
requests it.
3. Follow the on-screen instructions to complete USB installation.
4. On Assign USB device alias screen, click Cancel.
5. Run the Connection Expert program. It can be opened by double clicking the
icon in the task bar notification area or from the windows task bar,
Start>All Programs>Agilent IO Libraries Suite>Agilent Connection
Expert.
6. You have successfully completed Step 2 of the 3 Step Process. To complete the
confidence check for:
• Bluetooth GMA, refer to Step 3 “Using the GMA” on page 35.
• WLAN, refer to Step 3 “Rename the Test Set in Connection Wizard.” on
page 31.
• SCPI, refer to Step 3 “Sending SCPI commands” on page 28.
N4010-90086.book Page 19 Monday, November 18, 2013 9:20 AM
