Making Your First Measurements
Connecting USB, GPIB or LAN
Chapter 220
Connecting by GPIB
Changing the GPIB Address
The GPIB address is an integer between 0 and 30. The Test Set is shipped with a
default address set to 15. The GPIB address is stored in non-volatile memory.
To change the GPIB address manually.
Press
System, .
Use the Numeric keys on front panel to enter the required GPIB address in the field.
Press the
softkey.
Connecting to your Computer
1. Follow your GPIB interface card vendor’s instructions for installing and
configuring GPIB hardware on your computer.
2. Connect a GPIB cable between your computer and the Test Set.
3. Run the Connection Expert program. It can be opened by double clicking the
icon in the task bar notification area or from the windows task bar,
Start>All Programs>Agilent IO Libraries Suite>Agilent Connection
Expert.
In the Connection Expert program, click on Refresh All.
N4010-90086.book Page 20 Monday, November 18, 2013 9:20 AM
