Agilent Technologies N4010A User Manual

Making Your First Measurements
Running the Graphical Measurement Application (GMA) N4017A.
Chapter 2 33
Running the Graphical Measurement Application
(GMA) N4017A.
The N4017A Bluetooth Graphical Measurement Application, is a PC based software
application that works in a complementary manner with the N4010A Wireless
Connectivity Test Set. The GMA makes it possible to fully configure the Test Set
remotely.
To operate with the Bluetooth GMA, your N4010A Test Set must be configured
with:
• Firmware revision A.02.00.11 or later
• Option 101
• Option 110
Refer to the N4010A web page at www.agilent.com/find/N4010A for firmware
updates.
To verify your configuration, press the
System key, an example is shown in Figure
2-15.
Figure 2-15 Typical System Configuration Screen
N4010-90086.book Page 33 Monday, November 18, 2013 9:20 AM

Agilent Technologies N4010A Specifications

General

Brand	Agilent Technologies
Model	N4010A
Category	Test Equipment
Language	English
