Making Your First Measurements
Connecting USB, GPIB or LAN
Chapter 2 25
6. In the pop up screen, shown in Figure 2-9, select the IP Address link.
7. Enter the IP address which is displayed on the Test Set.
8. Click on Test Connection.
9. Click on Identify Instrument.
Figure 2-9 LAN Instruments Selection Screen
10. Confirm the returned serial number matches the Test Set.
11. Click on OK.
To complete the confidence check for
• Bluetooth GMA, refer to Step 3 “Using the GMA” on page 35.
• WLAN, refer to Step 3 “Running the Test Harness Program.” on page 31.
• SCPI, refer to Step 3 “Sending SCPI commands” on page 28.
N4010-90086.book Page 25 Monday, November 18, 2013 9:20 AM
