Default Setting Configurations 3
U1241B/U1242B User’s and Service Guide 27
Table 3 -9 Available setting options in Setup mode
Menu item Available setting options Default factory
setting
Setup Description Selection Description
rHd Trigger hold OFF Enables Data Hold (manual trigger) 500
100–1000 Sets variation count that determines Refresh Hold
(auto trigger)
SCA Percentage scale 0–20 mA,
4–20 mA
Sets % scale readout for 0 to 20 mA or 4 to 20 mA 4–20 mA
FrE Minimum frequency
can be measured
0.5 Hz, 1 Hz,
2 Hz, 5 Hz
Sets the minimum frequency that can be
measured in AC measurement mode
0.5 Hz
bEP Frequency of beep
sound
2400 Hz,
1200 Hz,
600 Hz, 300 Hz
Sets frequency of beep sound of the multimeter 2400 Hz
OFF Disables beep sound of multimeter
Thermocouple tYPE Sets thermocouple type to K-type tYPE K
tYPE
[1]
Sets thermocouple type to J-type (for U1242B)
tYPE mV Sets 100 mV measurement for T1 input
Log Data logging (for
U1242B)
Hand Enables manual data logging Hand
1–9999 Sets interval for automatic data logging from 1 to
9999 seconds. Press to toggle through the
digit to be adjusted.
APF Auto power off
[1]
1–99 m Sets timer in minutes for auto power off 15 m
OFF Disables auto power off
Lit Backlight timer 1–99 Sets timer in seconds for auto turn-off for
backlight display
15
OFF Disables auto turn-off for backlight display
dAC Default AC or DC for
voltage and current
measurements
dC, AC Defines the preferred setup of AC or DC for
voltage and current measurement once
multimeter is turned on.
dC
rSt Reset dFAU Resets the multimeter to the factory settings by
pressing and holding for more than 1
second. A beep sound indicates the reset is being
done.
dFAU
tnP
