Table 3 - 9 Available setting options in Setup mode
Menu item Available setting options Default factory
setting
Setup
Description
Selection Description
rHd
Trigger hold
OFF Enables Data Hold (manual trigger) 500
100–1000 Sets variation count that determines Refresh
Hold (auto trigger)
SCA
Percentage scale
0–20 mA,
4–20 mA
Sets % scale readout for 0 to 20 mA or 4 to 20 mA 4–20 mA
FrE
Minimum frequency
can be measured
0.5 Hz, 1 Hz,
2 Hz, 5 Hz
Sets the minimum frequency that can be mea-
sured in AC measurement mode
0.5 Hz
bEP
Frequency of beep
sound
2400 Hz,
1200 Hz,
600 Hz, 300 Hz
Sets frequency of beep sound of the meter 2400 Hz
OFF Disables beep sound of meter
Thermocouple
tYPE Sets thermocouple type to K-type tYPE K
tYPE
[1]
Sets thermocouple type to J-type (for U1242A)
tYPE mV Sets 100 mV measurement for T1 input
Log
Data logging (for
U1242A)
Hand Enables manual data logging Hand
1–9999 Sets interval for automatic data logging from 1 to
9999 seconds. Press to toggle through the
digit to be adjusted.
APF
Auto power off
[1]
1–99 m Sets timer in minutes for auto power off 15 m
OFF Disables auto power off
Lit
Backlight timer
1–99 Sets timer in seconds for auto turn-off for back-
light display
15
OFF Disables auto turn-off for backlight display
dAC
Default AC or DC for
voltage and current
measurements
dC, AC Defines the preferred setup of AC or DC for volt-
age and current measurement once meter is
turned on.
dC
rSt
Reset
dFAU Resets the meter to the factory settings by press-
ing and holding for more than 1 second.
A beep sound indicates the reset is being done.
dFAU
