3 Using the Scope Functions
72 Agilent U1602B/U1604B User’s and Service Guide
Figure 3-34 Y-cursor measurement for channel 1 signal with Y1 and Y2 cursor lines
5 In Figure 3- 34, the measurement is made for the signal at channel 2.
The Y1 measurement is –13.60 mV
.
The Y2 measurement is +56.80 mV.
The delta of Y1 and Y2 voltage measurement is +70.40 mV.
Y1 cursor line
Y2 cursor line
Y1, Y2 and delta
measurement
