Characteristics and Specifications 9
172 Agilent U1602B/U1604B User’s and Service Guide
Specifications
All specification are warranted. Specifications are valid after a 30- minute
warm- up period and within ± 10 °C from firmware calibration
temperature.
Table 9 - 1 Warranted specifications
SCOPE SPECIFICATIONS
Vertical System: Scope Channels
Bandwidth (–3 dB) U1602B: DC to 20 MHz
U1604B: DC to 40 MHz
DC vertical gain accuracy 5 mV/div to 20 mV/div: ± 5% full scale
50 mV/div to 100 V/div: ± 3% full scale
Scope Channel Triggering
Trigger sensitivity DC to 5 MHz: 0.8 divisions
U1602B: 5 MHz to 20 MHz — 1 division
U1604B: 5 MHz to 40 MHz — 1 division
