2Front Panel and Displays Overview
20 Agilent U1602B/U1604B User’s and Service Guide
1 Power Switch Press and hold power switch button to power the
instrument ON or OFF.
2 Softkeys The function of each key varies with the menus shown on the
display. The four softkeys are located below the LCD display.
3 Scope Main function key to access channel 1 and channel 2 waveform
settings. Under Scope mode, you can set the waveform display to
delayed section, whereby you can select XY and YT time base. By
turning the rotary switch, you can change the waveform’s vertical
position on the display. You can also set the acquisition window relative
to the trigger point and trigger time reference point on this menu. In
addition to this, you can pan and zoom into the virtual waveform by
turning the zoom window horizontally.
4 Meter Main function key to switch to multimeter mode. This meter
mode provides access to Voltmeter, Ohmmeter and Auxiliary meter
sub- menu. Use the softkey to select and access the various multimeter
functions that work in auto- range mode.
5 Logger Main function key to consolidate data point for data logging
purposes. This data logging function is available for all multimeter
functions.
6 User Main function key to access Display, Acquire, Math and Utility
menus.
•Display mode allows you to set the type, contrast and graticule setting
for the display background. You can persist the captured waveform
without erasing the previous waveform acquisitions.
•Acquire mode lets you set the signal acquisition to Normal, Average or
Peak modes.
•Math mode provides the Dual Waveform Math functions to multiply and
subtract waveforms. FFT (Fast Fourier Transform) function is available
for U1604B.
