U1731B/U1732B User’s and Service Guide
1G
e
t
t
i
n
g
S
t
a
r
t
e
d
The Front Panel at a Glance
Figure 1-1
Front panel of U1731
B and U1732B du
al display handheld LCR meter
U1732B
U1731B
Annunciator
display
Keypad
Input
terminals
15
17
