Specification Validation
You can perform self- validation of the LCR meter's accuracy by using the
recommended equipment with the specified test ranges below.
Table 3 - 1 Resistance ranges for functional validation
Resistance (Parallel Mode), Test Frequency: 100 Hz, 120 Hz, 1000 Hz, or 10 kHz
Table 3 - 2 Capacitance ranges for functional validation
Capacitance (Parallel Mode), Test Frequency: 100 Hz, 120 Hz, 1000 Hz, or 10 kHz
Recommended Equipment: IET 1433 Resistor Box
Range (W) Test Value Used
200 k 100 k
2000 1000
20 10
Recommended Equipment: HACS-Z Precision
Decade Capacitor
Range (F) Test Value Used
20 µ 10 µ
200 n 100 n
20 n 10 n
200 p
*
* Does not support test frequency of 100 Hz, 120 Hz,
and 1000 Hz
100 p
