Agilent Technologies U3402A User's And Service Guide

6 Specifications and Characteristics
106 U3402A User’s and Service Guide
[1]
Reference impedance is displayed on the secondary display.
[2]
Reading displayed in watts (Audio power).
[3]
For calibration use only.
Measurement Specification
Measurement
Noise Rejection
Common mode reject
ratio (CMRR) for 1 k
W
unbalanced LO lead
50/60 Hz ± 0.1%: DC >90 dB
Normal mode rejection
ratio (NMRR)
50/60 Hz ± 0.1%: >50 dB
dBm Operation 0 dBm 1 mW at 600
W reference impedance
Resolution
Slow: 0.01 dB for all ranges
Medium: 0.01 dB for all ranges
Fast: 0.1 dB for all ranges
Reference impedance
[1]
2 W
[2]
, 4 W
[2]
, 8 W
[2]
, 16 W
[2]
, 50 W , 75 W , 93 W , 110 W ,
124
W , 125 W , 135 W , 150 W , 250 W , 300 W , 500 W , 600
W , 800 W , 900 W , 1000 W , 1200 W , or 8000 W
Math Operation dBm, Rel, MinMax, Comp, Hold
I/O Interface
RS232
[3]
Table 6-13 Supplemental measurement specifications
NOTE
When V
ac+dc
measurement function is selected, the VDC input impedance is parallel with
an AC-couples 1.1 M
W divider.
