4 agria Multi-Purpose Machine 400E/400K
Designation of Parts Type 400E
Figure A
1 Pto speed shift lever
2 Linkage for front attachments
3 Transmission oil plug (filling and checking oil level)
4 Linkage for rear attachments
5 Grooves on wheel shaft
6 Wheel shaft
7 Gearbox cover/Transmission oil drain opening
8 Pto/pto guard
9 Name plate (machine identification no.)
10 Handlebar
11 V-belt guard (V-belt clutch)
12 Drive wheel
13 Drive-wheel detent spring
14 Guard
Figure B
1 Air filter
2 Carburetor
3 Fuel tank cap
4 Fuel tank
5 Choke lever
6 Engine type no.
7 Starter handle
8 Cooling air-screen
9 Exhaust with guard
10 Spark plug/spark plug connector
11 Engine oil filler plug and control opening
12 Engine oil drain plug
13 Fuel tap (only version Power Built 190)
