Chapter 2. Hardware SetupLynx User Manual
2�1�2 Processor Heat Sink Module and Processor Socket Assembly
Each processor socket on the server board is pre-assembled with a loading mechanism that
is designed to secure the Processor Heat Sink Module (PHM) to the server board as shown
below.
WARNING
Previous generations of the Intel Xeon Processors and heatsinks are not compatible with the
Intel Server Board S2600BP Product Family. Processor installation requires that the processor
be attached to the installation onto the server board.
