Chapter 4. BIOS Conguration SettingsLynx User Manual
Intel® VMD
technology
Intel® AIC
Retimer/AIC SSD
Technology (non-
VMD)
Intel® AIC
Retimer/
AIC SSD on
Socket 0~1
Intel® AIC
Retimer/AIC
SSD HW at
PStack0~2
Enable Disable
Port A
Port B
Port C
Port D
Enable Disable
Hot Plug
Capable
Enable Disable
FIOAT
Conguration)
Disable TPH Yes No
Prioritize TPH Enable Disable
Relaxed Ordering Enable Disable
Sck0~1 IOAT
Cong
DCA Enable Disable
IOAT Function
1~7 Items
DMA
Enable
Disable
No snoop
Enable
Disable
IIO DFX
Conguration
EV DFX Features Enable Disable
Ltssm Logger Enable Disable
Stop Min=0x0, Max=0x99
Speed
Gen 1 (2.5
GT/s)
Gen 2 (5 GT/
s)
Gen 3 (8 GT/
s)
Mask Enable Disable
Jitter Logger Enable Disable
4.4.10 ME Conguration
ME Conguration
Server ME
Conguration
General ME
Conguration
Altitude Min=0x0, Max=0xffff
MCTP Bus Owner Min=0x0, Max=0xffff
Server ME
Debug
Conguration
Server ME General
Conguration
ME Initialization
Complete Timeout
Min=0, Max=12
Enable HSIO
Messaging
Enable Disable
DRAM Init
Done Enable
0 1 None
DRAM Initialization
Status
Auto - true status 0 - Success
1 - No Memory in
Channels
2 - Memory Init
Error
Host Reset
Warning
0 1 None
