Chapter 2. Hardware SetupLynx User Manual
3�2 Motherboard Content List
Connector/Header/Jumper Location Connector/Header/Jumper Location
1a
1b
Power Supply COM
Bus Disable Jumper
J15, J16 21
CPU0 Configurations
Jumper
JPG_LOCK
2a
2b
Power Supply PSKILL
Disable Jumper
J14, J17
22a
22b
COM Port JCOM1, JCOM4
3a
3b
3c
3d
Backplane Power
Header
JPWR1, JPWR2,
JPWR3, JPWR4
23
BMC Debug Port
Header
JBMC_DP
4
Power Supply
Connector:
12V, 5VSB
JPWR5 24 Buzzer Header JBUZZER
5
PS_ON Enable
Jumper
J18 25 LCM Header JLCM
6
Power Supply PMBus
Header
JPMBUS_PDB 26 Intruder JINTRUDER
7 PMBUS Connector JPMBUS 27
OCP Connector (KR
Function)
CN7
8a
8b
8c
8d
8e
8f
8g
Fan 3B Connector
Fan 3A Connector
Fan 4 Connector
Fan 1A Connector
Fan 1B Connector
FAN 2A Connector
FAN 2B Connector
J19
J20
J23
J25
J26
J28
J27
28a
28b
OCP Connector (PCIE) CN5, CN6
9a
9b
Power Supply
Connector: 12V
JPWR6, JPWR7
29a
29b
Riser Connector CN3, CN4
10a
10b
10c
PCH Fan Connector
CPU0 Fan Connector
CPU1 Fan Connector
J4
J21
J22
30a
30b
Riser Connector CN8, CN9
11 DIMM Sockets
JEDEC Specified
DDR4 Connector
31a
31b
HFI Connector JHFI1, JHFI2
12a
12b
12c
External-1 Thermal
Sensor
J8, J11, J24 32
BMC Debug Port Select
Jumper
J2
13a
13b
Front I/O USB Header
JUSB_INT1,
JUSB_INT2
33 IPMB Header JBMC_I2C1
14
Front I/O USB 2.0
Header
JUSB20 34 BMC Disable Jumper JBMC_DIS
15 OCuLink Connector JSYS_EXT 35 BMC Reset Jumper JBMC_RST
16a
16b
BMC GPIO Header
JBMC_GPIO1,
JBMC_GPIO2
36 Serial ATA
SATA1, SATA2,
SATA3, SATA4,
SATA5, SATA6,
SATA7, SATA8,
SATA9, SATA10
17 Front Panel Header JFRNT_SSI 37
SATA6 Pin-7 Power
Header
J12
18 PCH SGPIO Header JSGPIO 38
SATA5 PIN-7 Power
Header
J13
19a
19b
OCP Connector
(PCIE)
CN1, CN2 39 BMC I2C10 Header JBMC_I2C10
20 PCH SSGPIO Header JSSGPIO 40 PCH GPIO Header JPCH_GPIO
