50
Chapter 4. BIOS Conguration SettingsLynx User Manual
IIO IOAPIC Stack
0~5
Enable Disable
Intel® VT for
Directed I/O (VT-d)
Intel® VT for
Directed I/O (VT-d)
Enable Disable
Interrupt
Remapping
Enable Disable
PassThrough DMA Enable Disable
ATS Enable Disable
Posted Interrupt Enable Disable
Coherency Support
(Non-Isoch)
Enable Disable
Intel® VMD
technology
Intel® VMD
for Volume
Management
Device on
Socket 0/1
VMD
Cong for
PStack0~2
Intel® VMD
for Volume
Management
Device for
PStack0
Enable
Disable
VMD port A
VMD port B
VMD port C
VMD port D
Enable
Disable
Hot Plug
Capable
Enable
Disable
Cfg Bar size
Min=20,
Max=27
Cfg Bar
attribute
64-bit
prefetchable
Cfg Bar
attribute
32-bit non-
prefetchable
64-bit non-
prefetchable
64-bit
prefetchable
Mem Bar 1
size
Min=20,
Max=39
Mem Bar 1
attribute
32-bit non-
prefetchable
64-bit non-
prefetchable
64-bit
prefetchable
Mem Bar 2
size
Min=20,
Max=39
Mem Bar 2
attribute
32-bit non-
prefetchable
64-bit non-
prefetchable
64-bit
prefetchable
