Chapter 4. BIOS Conguration SettingsLynx User Manual
IIO
Conguration
PCIE Coherent
Read Partial
PCIRd Cur Setting, PRd Setting
PCIE Coherent
Read Full
PCIRd Cur Setting, PRd Setting
PCI-E Completion
Timeout (Global)
Disable
Per-port Yes No
PCI-E Global
Timeout Value
50m~64s
PCI-E ASPM
Support (Global)
Per-port L1 Only Disable
PCIE Stop &
Scream Support
Enable Disable
Snoop Response
Hold Off
Min=0x0, Max=0xf
PCIe Latency
Tolerance
Reporting
Auto Enable Disable
PCIe Extended Tag
Enable
Auto Enable Disable
PCIe Atomic
Operation Request
Support
Enable Disable
PCIe Max Read
Request Size
Auto
128B, 256B, 512B, 1024B,
2048B, 4096B
PcIe Relaxed
Ordering
Enable Disable
PCIe PHY test
mode
Enable Disable
Socket0/1
Conguration
IOU0 (IIO PCIe Br1)
Auto x4x4x4x4
x4x4x8 x8x4x4
x8x8 x16
IOU1 (IIO PCIe Br2)
Auto x4x4x4x4
x4x4x8 x8x4x4
x8x8 x16
IOU2 (IIO PCIe Br3)
Auto x4x4x4x4
x4x4x8 x8x4x4
x8x8 x16
MCP0 (IIO PCIe
Br4)
Auto x16
MCP1 (IIO PCIe
Br5)
Auto x16
PCI-E Completion
Timeout Disable
Yes No
PCI-E Completion
Timeout Value
50μs to 10ms,16ms to 55ms,65ms to
210ms,260ms to 900ms,1s to 3.5s,4s
to 13s,17s to 64s
