Chapter 4. BIOS Conguration SettingsLynx User Manual
UPI
Conguration
UPI Dfx
Conguration
Halt at UPI
Link Train
Failure
Auto Enable Disable
UPI Max Init
Abort
Auto Enable Disable
Llc Share
Drd Crd
Auto Enable Disable
CBo Bias Fwd
Mode
Auto Mode 0 Mode 1
Mode 2 Mode 3 Mode 4
Snoop Fanout Auto Enable Disable
Hit Me Auto Enable Disable
Enable Force
FwdInvItoE
Auto Enable Disable
DBP Enabled Auto Enable Disable
OSB Enabled Auto Enable Disable
HitME RFO
DirS Enabled
Auto Enable Disable
Gate OSB
IODC
Allocation
Enabled
Auto Enable Disable
Dual Link
Interleave
Mode
Auto Disable D2C
Enable CHA
interleaving
(disable SNC,
XOR-based
Intlv)
Dfx System
Degrade
Mode
Degrade_
to_1S
Degarde_to_
Supported
No_Degrade
VN1 Auto Enable Disable
Direct To Core
(D2C)
Auto Enable Disable
Direct To UPI
(D2K)
Auto Enable Disable
Memory
Conguration
Integrated Memory
Controller (iMC)
Enforce POR Auto Por Disable
PPR Type
Auto Hard PPR
Soft PPR PPR Disabled
PPR Error
Injection test
Enable Disable
Memory
Frequency
Auto 800~4400-OvrClk
IMC BCLK Auto 100MHz 133MHz
MRC Promote
Warnings
Enable Disable
Promote
Warnings
Enable Disable
Halt on mem
Training Error
Enable Disable
