Aidcall Touchsafe Pro - Fixed Reminders; Fixed Reminders Display; Cancel Fixed Reminder

Doc No. FM5600 issue E Page 32
21. SPECIFICATION
Single Charger
Aidcall Part No.
ZNC581 (previously Aidcall W07508 or Bluebell BRS01)
Mounting Options
Free Standing or Wall Mounted
Plug-Top PSU Module
12V DC 1.0A (Modified Power Pax SW4010G)
LED Indicator
Blue = Power
Enclosure Material
18 SWG Mild Steel
Finish
Polyester Powder Coated Semi-Gloss Grey White (RAL 9002)
Dimensions
35mm x 100mm x 50mm (HxWxD)
Weight
180 grams (excluding PSU)
Operating Temperature Range
-5
o
C to 40
o
C
Single Charger PSU Module
Power Pax Part No.
SW4010G
Input Voltage
100-240VAC 50/60Hz 0.4A Max
Output Voltage/Power
12V DC 12W
Max Output Current
1.0A
Output Plug
Modified: Barrel Plug Centre Positive changed to 1.3 x 5.0 x 12mm
Output Cable
1.8 metres
Dimensions
79mm x 50mm x 38mm (HxWxD)
Weight
110 grams
Operating Temperature Range
0
o
C to 50
o
C
5 Way Charger
Aidcall Part No.
ZNC582 (previously Aidcall W07507 or Bluebell BRM01)
Mounting Options
Free Standing or Wall Mounted (optional 45
o
bracket required)
Plug-Top PSU Module
12V DC 1.0A (Power Pax SW4010G)
LED Indicator
Blue = Power
Enclosure Material
18 SWG Mild Steel
Finish
Polyester Powder Coated Semi-Gloss Grey White (RAL 9002)
Dimensions
95mm x 240mm x 36mm (HxWxD)
Weight
760 grams (excluding PSU)
Operating Temperature Range
-5
o
C to 40
o
C
5 Way Charger PSU Module
Power Pax Part No.
SW4010G (Aidcall W00562)
Input Voltage
100-240VAC 50/60Hz 0.4A Max
Output Voltage/Power
12V DC 12W
Max Output Current
1.0A
Output Plug
Barrel Plug Centre Positive 2.1 x 5.0 x 12mm
Output Cable
1.8 metres
Dimensions
79mm x 50mm x 38mm (HxWxD)
Weight
110 grams
Operating Temperature Range
0
o
C to 50
o
C
Optional 45
o
Wall Bracket
Aidcall Part No.
W07516
Bracket Material
16 SWG Mild Steel
Finish
Polyester Powder Coated Semi-Gloss Grey White (RAL 9002)
Dimensions
95mm x 235mm x 60mm (HxWxD)
Weight
490 grams
