The paging system Interface, Master Base, Slave Base, Wireless Slave and Repeaters are all housed in the
same type of ABS enclosure. Always check the Model No. label on the rear of the unit to be sure of which
product you are looking at.
LED INDICATORS
The GREEN LED should be permanently illuminated when the external 12V supply is connected.
The GREEN/YELLOW LED should flash every 2 seconds – on an Interface this indicates RS485 polling, on all
other units it indicates radio communications are healthy.
The BLUE LED should be normally on and flash off when data is received by the Paging Interface from the
Nursecall system.
