Chapter 3 – System Functions
A
A
i
i
U
U
I
I
n
n
t
t
3
3
2
2
u
u
l
l
_
_
T
T
r
r
g
g
S
S
o
o
u
u
r
r
c
c
e
e
Value
Constant
Restriction
Description
0
API_TRG_PXI0
PXI Trigger Line 0
1
API_TRG_PXI1
PXI Trigger Line 1
2
API_TRG_PXI2
PXI Trigger Line 2
3
API_TRG_PXI3
PXI Trigger Line 3
4
API_TRG_PXI4
PXI Trigger Line 4
5
API_TRG_PXI5
PXI Trigger Line 5
6
API_TRG_PXI6
PXI Trigger Line 6
7
API_TRG_PXI7
PXI Trigger Line 7
8
API_TRG_BC_CHN1
Onboard BC Trigger of Channel 1
9
API_TRG_BC_CHN2
Only on ACX1553-2-3U and
ACX1553-4-3U available
Onboard BC Trigger of Channel 2
10
API_TRG_BC_CHN3
Only on ACX1553-4-3U available
Onboard BC Trigger of Channel 3
11
API_TRG_BC_CHN4
Only on ACX1553-4-3U available
Onboard BC Trigger of Channel 4
12
API_TRG_RT_CHN1
Onboard RT Trigger of Channel 1
13
API_TRG_RT_CHN2
Only on ACX1553-2-3U and
ACX1553-4-3U available
Onboard RT Trigger of Channel 2
14
API_TRG_RT_CHN3
Only on ACX1553-4-3U available
Onboard RT Trigger of Channel 3
15
API_TRG_RT_CHN4
Only on ACX1553-4-3U available
Onboard RT Trigger of Channel 4
16
API_TRG_BM_CHN1
Onboard BM Trigger of Channel 1
17
API_TRG_BM_CHN2
Only on ACX1553-2-3U and
ACX1553-4-3U available
Onboard BM Trigger of Channel 2
18
API_TRG_BM_CHN3
Only on ACX1553-4-3U available
Onboard BM Trigger of Channel 3
19
API_TRG_BM_CHN4
Only on ACX1553-4-3U available
Onboard BM Trigger of Channel 4
20
API_TRG_BM_HS
Only on ACX3910-3U available
Onboard BM HS Trigger
A
A
i
i
U
U
I
I
n
n
t
t
3
3
2
2
u
u
l
l
_
_
T
T
r
r
g
g
D
D
e
e
s
s
t
t
Value
Constant
Restriction
Description
0
API_TRG_PXI0
PXI Trigger Line 0
1
API_TRG_PXI1
PXI Trigger Line 1
2
API_TRG_PXI2
PXI Trigger Line 2
3
API_TRG_PXI3
PXI Trigger Line 3
4
API_TRG_PXI4
PXI Trigger Line 4
5
API_TRG_PXI5
PXI Trigger Line 5
6
API_TRG_PXI6
PXI Trigger Line 6
7
API_TRG_PXI7
PXI Trigger Line 7
8
API_TRG_BC_CHN1
Onboard BC Trigger of Channel 1
9
API_TRG_BC_CHN2
Only on ACX1553-2-3U and
ACX1553-4-3U available
Onboard BC Trigger of Channel 2
10
API_TRG_BC_CHN3
Only on ACX1553-4-3U available
Onboard BC Trigger of Channel 3
11
API_TRG_BC_CHN4
Only on ACX1553-4-3U available
Onboard BC Trigger of Channel 4
12
API_TRG_RT_CHN1
Onboard RT Trigger of Channel 1
13
API_TRG_RT_CHN2
Only on ACX1553-2-3U and
ACX1553-4-3U available
Onboard RT Trigger of Channel 2
14
API_TRG_RT_CHN3
Only on ACX1553-4-3U available
Onboard RT Trigger of Channel 3
15
API_TRG_RT_CHN4
Only on ACX1553-4-3U available
Onboard RT Trigger of Channel 4
16
API_TRG_BM_CHN1
Onboard BM Trigger of Channel 1
17
API_TRG_BM_CHN2
Only on ACX1553-2-3U and
ACX1553-4-3U available
Onboard BM Trigger of Channel 2
18
API_TRG_BM_CHN3
Only on ACX1553-4-3U available
Onboard BM Trigger of Channel 3
19
API_TRG_BM_CHN4
Only on ACX1553-4-3U available
Onboard BM Trigger of Channel 4
20
API_TRG_BM_HS
Only on ACX3910-3U available
Onboard BM HS Trigger
