Chapter 9 – Bus Monitor Functions
9.1.5 ApiCmdBMFilterIni
Prototype:
AiInt16 ApiCmdBMFilterIni ( AiUInt32 ul_ModuleHandle, AiUInt8 biu, AiUInt8 rt_addr,
AiUInt32 rx_sa, AiUInt32 tx_sa, AiUInt32 rx_mc,
AiUInt32 tx_mc );
Driver Command:
API_BM_INI_MSG_FLT (0xC0)
Purpose:
This function is used to provide a filter capability on RT Subaddress and Mode code
level for the specified RT Address. As a default, all Message Capture Enable / Filter
bits are set with the ApiCmdBMIni function.
