Chapter 4 – Calibration Functions
4 CALIBRATION FUNCTIONS
Chapter 4 defines the Calibration function calls of the API S/W Library. The Calibration
functions provide configuration of the physical MILbus including coupling mode, transmitter
amplitude output and data rate (default 1 Mbps). Table 4-I defines the list and definition of
Calibration function calls. The function calls in this table are listed in a functional order,
however, the detailed descriptions of the Calibration function calls in the following sections are
in alphabetical order.
Table 4-I – Calibration Function Descriptions
Function
Description
ApiCmdCalCplCon
Sets up the physical MILbus coupling mode
ApiCmdCalSigCon
Enables/disables 1 Mhz square wave calibration test signal
ApiCmdCalTransCon
Controls the data rate of MILbus (500 kbps or 1 Mbps).
ApiCmdCalXmtCon
Modifies the output amplitude of the MILbus/test signal
