MIL-STD-1553 Reference Manual
1.3.5 Buffer Header ID, Buffer ID and Transfer ID Ranges
In several function calls, a Buffer Header ID, Buffer ID or Transfer ID parameter is
required. The ID's maximum value depends on the settings applied with the function
ApiCmdSysSetMemPartition.
If the ApiCmdSysSetMemPartition function is not applied, the following default ranges
are valid for each function in which a Buffer Header ID, Buffer ID or Transfer ID
parameter appears. All Ids are always valid for one Global Memory Bank:
Table 1.3.5-I Transfer ID/ Buffer Header ID Ranges
Transfer ID / Buffer Header ID Ranges
Note: If setting up both LS and HS transfers, be sure not to use the same Ids, because
the Ids are shared between LS and HS!!!
Table 1.3.5-II Buffer ID Ranges
