8.1.25 ApiCmdRTStatusRead
Prototype:
AiInt16 ApiCmdRTStatusRead ( AiUInt32 ul_ModuleHandle, AiUInt8 biu,
TY_API_RT_STATUS_DSP *pdsp );
Driver Command:
API_RT_STATUS_READ (0x9A)
Purpose:
This function is used to read the execution status of the RT operation and the global
RT message and error counters.
