Chapter 9 – Bus Monitor Functions
9.1.42 ApiCreateScopeBuffer
Prototype:
TY_API_SCOPE_BUFFER* ApiCreateScopeBuffer(
AiUInt32 ulModuleHandle,
AiUInt32 ulID,
TY_API_SCOPE_BUFFER_TYPE eBufferType,
TY_API_SCOPE_BUFFER_HANDLER pBufferHandler,
void* pvUserData);
Purpose:
This function allocates a scope buffer which can be used as input to the function
ApiProvideScopeBuffers. The MILScope data will be transferred directly into this
buffer with a DMA transfer. The buffer will be allocated with the required size
according to the MILScope setup. Before this function is called the function
ApiCmdScopeSetup must be called.
Note: This function is only usable with AIM’s APE MIL-Scope module.
