MIL-STD-1553 Reference Manual
Chapter 3 – System Functions
3 SYSTEM FUNCTIONS
Chapter 3 defines the System function calls of the API S/W Library. The System functions
provide general device control, response timeout setup, IRIG setup, board configuration status
and control of the generation of dynamic data words/datasets. Table 3-I defines the list and
definition of System function calls within this group. The function calls in this table are listed in
a functional order, however, the detailed descriptions of the System function calls in the
following sections are in alphabetical order.
Table 3-I – System Function Descriptions
Initializes AIM board and returns board configuration
Resets the AIM board and ASP driver software data to initial
state
Performs a selftest on the AIM board
Defines the response timeout value (default is 14 µsec)
Reads software version of AIM board target software
Returns the version # of all AIM board s/w package components
Returns the version # of all AIM board s/w package components
(Extended Version)
Configures up to 4 PCI and System Controller (PSC) s/w timers
Reads the interrupt status of the selected PSC s/w timer
Reads the interrupt status of the selected BIU
Downloads S-Record formatted strings to the AIM board target
Inserts data into the AIM board on-board Flash-PROM
Executes a system-related function on the AIM board
Sets the time of the on-board IRIG timecode encoder
Reads the time on the on-board IRIG timecode encoder
Defines MILbus Protocol type (A or B) for individual or single RTs
Provides for the storing of data recorded by the BM function to an
application buffer
Writes and copies replay data
Defines the generation of dynamic data words or datasets in BC
and RT mode
Suspends or resumes the generation of dynamic data words or
datasets in BC and RT mode.
Defines an area (track) in the 1553 Data Buffer to be copied and
stored in a Shared memory area and multiplexed with tracks from
subsequent buffers transmitted/received with the same XID/RT
SA
Reads the multiplexed 1553 message data defined as a track
with ApiCmdTrackDef
Configures the Global RAM of the board
Free a allocate a target software memory block
Read board information from the target software
Reads the configuration of the Global RAM of the board
Allocate a target software memory block
