MIL-STD-1553 Reference Manual
156
Chapter 4 – Calibration Functions
4.1.4 ApiCmdCalXmtCon
Prototype:
AiInt16 ApiCmdCalXmtCon ( AiUInt32 ul_ModuleHandle, AiUInt8 biu, AiUInt8 bus,
AiUInt8 amp );
Driver Command:
API_CAL_XMT_CON (0xD4)
Purpose:
This function is used to control the transmitter output amplitude of the selected MILBus
transceiver on the AIM board via the voltage control pins.
Input
A
A
i
i
U
U
I
I
n
n
t
t
8
8
b
b
u
u
s
s
Value
Constant
Description
1
API_CAL_BUS_PRIMARY
Primary MILbus
2
API_CAL_BUS_SECONDARY
Secondary MILbus
A
A
i
i
U
U
I
I
n
n
t
t
8
8
a
a
m
m
p
p
Value
Description
0..255
Register value for Output amplitude control of selected MILbus
(0 = 0%, 255 = 100%)
Note: The relationship between the physical output amplitude and the
value given with this parameter is nearly linear. The output amplitude
value depends on the adjusted coupling mode.
Output
n
n
o
o
n
n
e
e
Return Value
A
A
i
i
I
I
n
n
t
t
1
1
6
6
All API functions return API_OK if no error occurred. If the return value is not equal
to API_OK the function ApiGetErrorDescription can be used to obtain an error
description.
